0.75 CBM Underground Mine Diesel Scooptram 0.75m3 Underground Scooptram for coal mine
China Underground Electric Scooptram and LHD Loaders
Features:
1. Underground electric LHD adopt torque converter driving system, three-phase AC motor driving. Gear-box, torque converter, differential mechanism and drive axle are all imported international famous brand.
2. Special design and structure like small size, performing long lifespan, big shovel force, lower cost, convenient in operation and maintenance as well.
3. It has the characteristics of four-wheel drive, full-hydraulic steering, three-point articulated in front and rear car body.
4. Suitable for mining and road way drivage slag, the construction of the road and work place, material transportation and so on.
1.Pre-sale service:
Act as a good adviser and assistant of clients enable them to get rich and generous returns on their investments .
1.Select equipment model.
2.Design and manufacture products according to client's special requirement ;
3.Train technical personnel for clients .
2.Services during the sale:
1.Pre-check and accept products ahead of delivery .
2. Help clients to draft solving plans .
3.After-sale services:
Provide considerate services to minimize clients' worries.
1.Complete After-sales service,professional engineers available to service machinery at home or oversea.
2. 24 hours technical support by e-mail.
3. Call or door-to-door service
| Heaped Bucket Capacity:0.75m³ | Payload Capacity:1500kg |
| Max. Traction:41 KN | Max. Shovel Force :39KN |
| Running Speed:0—8km/h | Max. Climbing Ability :16° |
| Max .Discharge Height:850mm | Min. Turning Radius :2350mm |
| Max. Rotation Angle :±36° | Min. Ground Clearance: 195mm |
| Nominal Power :37kw | Max. Bucket Height:3600mm |
| Effective Cable Length :100m | Weight(include hydraulic oil):6.5T |
| Dimensions :5800*1250*1900 |
